The Hikrobot CMR CHA-300L-A belongs to the Lifting Series, an Autonomous Mobile Robot (AMR) built on a lifting platform that can be integrated with multiple end-effectors including cantilever shafts, push mechanisms, tension mechanisms, and sliding assemblies to automate complex material handling tasks in industrial environments.
The robot can dock with production equipment, machines, and tooling at various heights, depths, and configurations to automate material pickup, transportation, and delivery. It is an ideal solution for smart factories requiring direct integration between AMRs and manufacturing equipment.
The Hikrobot CHA-300L-A features a rated payload of 300 kg, a 3-inch cantilever shaft, and a pickup height range of 560–1490 mm. It supports both 2D Barcode and L-SLAM navigation while providing omnidirectional movement and 360° on-the-spot rotation.
With customizable cantilever shafts, adjustable docking heights, ±2 mm docking accuracy, and a comprehensive multi-layer safety system, the CHA-300L-A is well suited for automated machine docking, material roll transportation, and internal logistics between production processes.
Typical Applications
Buffer Rack Docking
The robot automatically docks with buffer racks or transfer stations to receive and deliver materials between production processes, reducing manual handling and improving internal logistics efficiency.
Direct Machine Docking
The robot performs precise docking with manufacturing equipment, enabling automated material loading and unloading throughout the production line.
Cantilever Shaft for Material Roll Handling
The cantilever shaft enables automatic pickup and transportation of rolled materials while ensuring accurate docking with storage racks and roll-processing equipment.
Key Features
Flexible End-Effector Integration
-
Supports multiple end-effectors including cantilever shafts, push mechanisms, tension mechanisms, and sliding assemblies for various material handling applications.
-
Customizable cantilever shafts are available to meet specific application requirements.
-
Supports custom docking heights for seamless integration with different production equipment.
Safe and Stable Robot Platform
-
Multi-layer safety protection includes a 360° laser obstacle avoidance system integrated into the chassis together with overhead 3D sensors.
-
Stable operation with a maximum travel speed of 1.0 m/s.
High-Precision Navigation & Positioning
-
Supports high-precision navigation using 2D Barcode, L-SLAM, and V-SLAM.
-
Secondary positioning provides docking accuracy of up to ±2 mm.
Wireless Connectivity & Manual Operation
-
Supports Wi-Fi and 5G connectivity for flexible operation.
-
Supports both wireless mobile applications and wired handheld controllers.
